Beamz LCB155 - Page 28

28
16 Channels 
Channel Function Value Description
1 Dimmer 000-255 Master dimming (0-100%)
2 Strobe 000-255 Stroboscope (Rate 0-100%)
3-14
Pixel Colour
(DMX channel / pixel)
000-009 No function
010-019 Red
020-029 Green
030-039 Blue
040-049 White
050-059 Amber
060-069 UV
070-079 Yellow
080-089 Magenta
090-099 Cyan
100-109 Dark orange
110-119 Green yellow
120-129 Salmon
130-139 Turquoise
140-149 Light Green
150-159 Orange
160-169 Straw
170-179 Lavender
180-189 Light blue
190-199 Dark blue
200-209 Pink
210-219 Cool white
220-255 Warm white
15 Auto / Sound mode
000-009 No function
010-039 Auto program1 (rate)
040-069 Auto program2 (rate)
070-099 Auto program3 (rate)
100-129 Auto program4 (rate)
130-159 Sound program1 (rate)
160-189 Sound program2 (rate)
190-219 Sound program3 (rate)
220-255 Sound program4 (rate)
16 Colour temperature
000-009
No function
010-049
White 2700k
050-089
White 3200k
090-129
White 4300k
130-169
White 5600k
170-209
White 6500k
210-255
White 8000k
