MCD-60
Side View
C.
Earphone jack
AUX-IN jack: auxiliary input 3.5 mm jack.
FM ANT: it is used to receive radio signal.
D.
DC 5V 2A power socket: connect the device to the power supply.
E.
USB interface
Installation
For tabletop use
The stand has to be attached to the main unit for tabletop use.
For wall mounting
Remove the stand from the main unit.
Make sure the marks are level before drilling.
Drill the holes on the marks.
See the illustration below.
