04
Objective Lens Switching Knob
Objective Lens
Lighting Adjusting
Knob
Platform Move Back
And Forth Button
100x / 600X / 1200X switch by rotation
Turn it on clockwise &
increase the brightness
Turn the brightness down
Rotate counterclockwise to move the left
platform backward
Rotate the platform clockwise and move it
forward
Platform Bottom Light
Adjustment Knob
Turn it on clockwise, turn it up,
turn it down
Focusing Knob
(Fine Adjustment)
Zoom out clockwise /
zoom in counterclockwise
Platform Lifting
Adjustment Knob
Decrease counterclockwise /
increase clockwise
Platform Left And
Right Movement Knob
Rotate counterclockwise and
move the platform to the left
Rotate the platform clockwise
and move it to the right
Knob Function Description
