Bebehut Trio-Fix - 4 ADJUSTABLE COMPONENT; 4.1 Adjust 5-point harness; 4.2 Adjust headrest

4 ADJUSTABLE COMPONENT
4.1 Adjust 5-point harness
Note: Before the adjustment, please make sure that headrest adjustment handle is at the lowest
level.
1. Pull out the shoulder belt while
pressing down the harness belt
adjuster to completely loosen the
5-point harness.
2. Open the back panel and lift up
the shoulder belt height adjuster
lever. Slide the shoulder belt
height adjuster to select the
optimal shoulder height for the
child. Lock down and fully engage
the adjuster rod after the height
is determined.
When at optimal height, The
shoulder belt should be at the
same level with or slightly above
child’s shoulder.
4.2 Adjust headrest
1. Lock down the shoulder belt
height adjuster to the highest
level (see step 2 in section 4.1).
