4.4 Remove 5-point harness

1. Loosen 5-point harness and open

the shoulder belt height adjuster

(see section 4.1). Take off and pull

out shoulder belts from the

harness belt connector and

shoulder belt height adjuster rod.

2. Take off shoulder belt pads and

store them in the gap between

child car seat base and backrest.

Pack and store shoulder belts in

the cell in the corner under seat

cover. Store the crotch belt in the

gap under seat cover.

3. Pull out the adjuster strap until it

is fastened. Make sure the

harness belt connector is stored

below the child car seat base. Roll

up the adjuster strap and pack it

into the hood of harness belt

adjuster.

5 CHILD GROUP 1 (9-18kg): ISOFIX + TOP

TETHER + 5-POINT HARNESS

1. Adjust 5-point harness to optimal

shoulder height. (see section 4.1)
