Appendix
Technical data and dimensioned drawing
Beck GmbH
Druckkontrolltechnik
Ferdinand-Steinbeis-Straße 4
71144 Steinenbronn
Operating instructions – Pressure Switch - Model-930...EX Rev.9
Page 14 of 18
Types / Pressure ranges
Type Adjustment range
for trip pressure
Switching
differential
Tolerance
band of
930.80 EX
20 300 Pa 10 Pa ±15 %
930.83 EX
50 500 Pa 20 Pa ±15 %
930.84 EX
30 400 Pa 15 Pa ±15 %
930.85 EX
200 1000 Pa 100 Pa ±15 %
930.86 EX
500 2500 Pa 150 Pa ±15 %
930.87 EX
1000 5000 Pa 250 Pa ±15 %
Note:
Switching pressure specifications apply to vertical installation which is also the recommended posi-
tion with pressure-pipe connections pointing downwards. If the switches are installed horizontally with
AMP connection terminals uppermost, the switching values are approx. 20 Pa higher.
Pressure connections:
2 plastic pipe connection pieces
external diameter: 6.0 mm
Maximum operating pressure:
10 kPa for all pressure ranges
Mounting position
Switching pressure specifications apply to vertical installation which is also the recom-
mended position with pressure-pipe connections pointing downwards. If the switches are in-
stalled horizontally with AMP connection terminals uppermost, the switching values are ap-
prox. 20 Pa higher.
Accessories
Various mounting brackets
(see Chapter 9.2)
Metal mounting bracket S-shaped
Metal mounting bracket L-shaped
Snap-on plastic bracket S-shaped
Snap-on plastic bracket L-shaped
Various connection kits
(see Chapter 9.2
)
Plastic tube for Climaset
©
Angled metall pipe for Climaset
©
Rubber grommet for Climaset
©
Roll with 100 m PVC hose
Various cable conduits
(see Chapter 9.2)
Cap nut conduit including sealing and counter screw
M20x1.5 cable conduit including sealing and counter screw
NPT1/2” cable conduit without counter parts
