 Documentation
 Operating instructions, conformity declaration, EC design test certificate
 System and zonal plan
 Proof of adherence to explosion protection regulations (see Appendix 9.34)
 Equipment selection: category, Equipment Protection Level EPL, temperature
class, explosion group, …
 Proof of adherence to intrinsic safety requirements
5 Start-up
Before voltage is applied to the equipment the following checks must be performed:
 Check that screws are firmly seated in
 Connecting terminals, protective earth conductor terminals and
potential equalisation terminals
 Housing cover
 Check
 The torque of the cable lead-in
 The tightness of the seal provided by the cable lead-in
 Check whether the equipment is ready for operation
 The parameterisation for this application must have been performed
 All interfaces such as inputs and outputs for control purposes must be connected
and ready for operation
5.1 Parameterisation
Equipment parameterisation
 Define all application-specific parameters.
 Adjustment of the pressure ranges
 With this pressure switch the pressure can be adjusted without a pressure gauge using a
scaled adjustment knob
 The switching differential can also be adjusted with a screwdriver by the adjustment screw
with the identification “-∆p+”
Type Adjustment range
for trip pressure
from
to
Switching
differential
Tolerance
band of
930.80 EX
20 300 Pa 10 Pa ±15 %
930.83 EX
50 500 Pa 20 Pa ±15 %
930.84 EX
30 400 Pa 15 Pa ±15 %
930.85 EX
200 1000 Pa 100 Pa ±15 %
930.86 EX
500 2500 Pa 150 Pa ±15 %
930.87 EX
1000 5000 Pa 250 Pa ±15 %
Note:
Switching pressure specifications apply to vertical installation which is also the recommended position
with pressure-pipe connections pointing downwards. If the switches are installed horizontally with AMP
connection terminals uppermost, the switching values are approx. 20 Pa higher.
 Once the power supply is applied, the equipment is ready for operation immediately.
