Becker DTM - Technical Data; Wavebands and Frequency Ranges; Output Power and Impedance; Input;Output Specifications

136
7HFKQLFDO'DWD
7HFKQLFDO'DWD
:DYHEDQGV : FM 87.5 MHz - 108 MHz
MW 531 kHz - 1620 kHz
LW 153 kHz - 282 kHz
SW 5800 kHz - 6250 kHz
)UHTXHQF\UDQJH : 20 Hz - 20 kHz for CD operations
30 Hz - 15 kHz for FM
50 Hz - 2.5 kHz for MW, LW, SW
2XWSXWSRZHU : 4 x 18 Watt
/LQHFURVVVHFWLRQ :min. 0.75 mm²
/RXGVSHDNHULPSHGDQFH :min. 4 Ω
/LQHRXW : 4 x analogue Line Out (Ua max 3Veff at 10 kΩ)
*$/ : In order to utilise the GAL, a square wave voltage
with a mass-related amplitude of +4 V - +12 V must come from the electronic tachometer of
the vehicle. Volume increase takes places in 7 increments of 2.5 dB each.
$QWHQQD : Impedance 50 Ω
$)7HOHSKRQHLQSXW : Max. input voltage of 8 V (if interference occurs, a commercially-available 1 : 1 carrier
should be connected to the signal lead).
$8;,QSXW :16 KΩ Input resistance, max. input voltage 1.7 Veff
7HOHSKRQH0XWH : Low active level < 2 Volt
6XSSO\YROWDJH :12 Volt
&'&RQQHFWLRQ : The Becker Silverstone 2630 and Silverstone 2660 CD changers can be connected.
3OD\DEOH&'V : Only those CDs which comply with DIN EN 60908 can be used.
The use of 8 cm CDs with adapter is not recommended.
