Technical data
Version: 2.1 ─── 17AS2000
Data for operation and
environment
Operate the motor only under the specified conditions
Operate motors only under the operating and environmental con-
ditions specified in this chapter. This ensures a long service life
and proper operation.
At temperatures above 40 °C and encapsulated installation, the
stepper motor may be damaged.
Beckhoff products are designed for operation under certain environ-
mental conditions, which vary depending on the product. The follow-
ing specifications must be observed for operation and environment
in order to achieve the optimum service life of the products.
Environmental requirements
Climate category 3K3 according to EN 60721
Ambient temperature at operation -10°C to +50°C
Ambient temperature at transport and storage Max. 20K/hour, fluctuating:
-20°C to +65°C
Permissible air humidity at operation 20% to 90% relative humidity, no condensation
Permissible air humidity at transport and storage 90% relative humidity, no condensation
Specifications for intended use
Insulation material class B; 130°C according to IEC 60085
Protection class
does not apply to the shaft bushing
Listed in the technical data of the motors
Mounting position See chapter: "Technical description", [Page39]
Ventilation Adequate self surface cooling is to be ensured.
Insulation resistance ≥ 100MΩ
Level of contamination 2 according to EN 60204 / EN 50178
Permissible operating altitude 1000m above sea level
Maximum cable length 10m
Corrosion protection The manufacturer must be consulted with regard to special measures for operation
under extremely corrosive conditions. These measures must be implemented imme-
diately by the user.
Special operating conditions The application and use of the motor are to be determined and assessed in the indi-
vidual case. Please consult the vendor in the case of harsher environmental and op-
erating conditions.
Approvals CE, EAC, UL; in preparation
