Commissioning
Name Type Description Default value
BatteryCapacity REG_DWORD Remaining UPS battery capacity in percent.
This element can adopt a value between 0
and 100 (the value displayed is rounded up).
0
BatteryStatus REG_DWORD Current status of the UPS battery. This
element can adopt the following values:
• 0 := the battery status is unknown;
• 1 := the battery status is OK;
• 2 := the battery must be exchanged;
0
CommStatus REG_DWORD Status of communication with the UPS. This
element can adopt the following values:
• 0 := the communication with the UPS
has an unknown status;
• 1 := the communication with the UPS is
OK;
• 2 := the communication with the UPS
has been interrupted.
0
FirmwareRev REG_SZ Returns the UPS firmware version number as
a string.
""
SerialNumber REG_SZ Returns the UPS serial number as a string. ""
TotalUPSRuntime REG_DWORD The remaining UPS battery time in minutes. 0
UtilityPowerStatus REG_DWORD Returns the status of the power supply. This
element can adopt the following values:
• 0 := the status of the power supply is
unknown;
• 1 := the power supply is OK;
• 2 := a power failure has been detected;
0
TcPowerFailCnt REG_DWORD Power failure counter. The counter increments
every time a power failure is detected.
0
BatteryReplaceDate REG_SZ Date of the last battery change. The date can
be set with a command in the Beckhoff UPS
Configuration dialog -> Device
Configuration…. Implemented in the UPS
software v3.0.0.8 and higher.
""
TcChargeFlags REG_DWORD Battery charge and status flags. This element
can adopt one or more values (bits) combined:
• 0 := unknown status (all bits are zero)
• 1 := charge status "High" (bit 0 is set);
• 2 := charge status "Low" (bit 1 is set);
• 4 := charge status "Critical" (bit 2 is set);
• 8 := charge status "Charging" (bit 3 is
set);
• Bit 4 - 6 reserved;
• 128 := No battery connected/found (bit 7
is set);
• 256 := UPS fan error (bit 8 is set);
• Bit 9 is reserved;
• 1024 := Battery change interval service
has expired (bit 10 is set). Implemented
in the UPS software v3.0.0.8 and
higher.
• Bit 11 - 31 reserved;
0
CX2100-09x4 63Version: 1.3
