Settings DIP switches RS485:

Table5: RS485 without Echo, End-Point ( Terminated) DEFAULT setting

DIP Status Function

1 off Echo on

2 on Echo off

3 on Auto send on

4 off Always send on

5 on Auto receive on

6 off Always receive on

7 on Term on

8 on Term on

Table6: RS485 with Echo, End-Point ( Terminated)

DIP Status Function

1 on Echo on

2 off Echo off

3 on Auto send on

4 off Always send on

5 off Auto receive on

6 on Always receive on

7 on Term on

8 on Term on

Table7: RS485 without Echo, Drop-Point ( without Termination)

DIP Status Function

1 off Echo on

2 on Echo off

3 on Auto send on

4 off Always send on

5 off Auto receive on

6 on Always receive on

7 off Term on

8 off Term on

Table8: RS485 with Echo, Drop-Point ( without Termination)

DIP Status Function

1 on Echo on

2 off Echo off

3 on Auto send on

4 off Always send on

5 off Auto receive on

6 on Always receive on

7 off Term on

8 off Term on
