Beckhoff TwinSAFE EJ Series - Specific Technical Data; Fig. 12 Addition of an EJ1918

EJ1918
EJ19xx and EJ29xx28 Version: 1.2.0
Fig.12: Addition of an EJ1918
7.3 Specific technical data
The EJ1918 Safety EtherCAT plug-in module is a digital input module for sensors for 24V
DC
. The EJ plug-in
module has 8 fail-safe inputs and meets the requirements of IEC61508:2010 SIL3 and
ENISO13849-1:2015 Category 4/PLe.
Product property EJ1918
Number of inputs 8
Number of clock outputs 8
Number of outputs -
Status indicator 8 (one green LED per input)
Diagnostic display 4 (1 green, 3 red LEDs)
Current consumption of the modular electronics at
24V (without current consumption of sensors)
8 channels occupied: typ. 26mA
0 channel occupied: typ. 3mA
Current consumption via E-bus 8 channels occupied: approx. 290mA
Weight approx. 60g
