USER MANUAL – MODELS 6002NA/V1/V2/ & 7002xx
QUESTIONS? EMAIL US AT INFO@BEDJET.COM OR CALL 401-404-5250
WE ARE HERE TO HELP – PLEASE CALL US FOR ADVICE!
Revision 1.6 www.bedjet.com P a g e | 15
5) Assemble Hose Mattress Mount using the Height Extending links as shown below. All
parts should snap together, thicker mattresses will require more Height Extender links:
6) Slide the Mattress Mount base under your mattress directly underneath the location
identified in step #3 for the Air Nozzle. The Mattress Mount will
be used to secure the Air Hose and Air Nozzle assembly against
the side of the bed Slide the Mattress Mount base as deeply as
possibly under the mattress until the Mattress Mount is flush
against the mattress.
7) Assemble Air Nozzle onto the Air Hose. Stretch and compress the
Air Hose, note how it can be expanded, contracted and bent to
retain any desired shape.
8) Push the fabric section of Air Hose onto Mattress Mount Hose Grip. Grip will stretch
open to accept the hose. Remove or
add Mattress Mount Height
Extending Links to adjust height of
the Hose Grip so that bottom of the
Air Nozzle rests on the top of the
mattress. The Hose Grip can be flush
against the plastic hose cuff or very
close to it – both installation
methods shown in photo are good. When finished, the Air Nozzle
should be resting on and project onto the mattress surface. Add
Height Links if Air Nozzle flops off mattress too easily.
9) Place BedJet on the floor near the bottom of the bed directly
beneath the Mattress Mount, the intake should be facing
towards the bed. Assemble the Air Hose onto air output port of
BedJet.
