Power Plant Instrument Markings
Power plant instrument markings and their color code significance are shown below:
Instrument
Red Line
Green Arc
Red line
Minimum
Limit
Normal
Operating
Maximum
Limit
Tachometer (GSAK)
2000 – 2700
2700
Tachometer (FXFG)
Red arc from 2000 to 2350 (avoid continuous operation between
2000 and 2350 rpm.
Red Line. Maximum 2700 rpm
Manifold Pressure
14.5 – 29
29
Fuel Flow
0 -17.8
(10 psi)
Oil temperature
140 - 245
245
Oil Pressure
25
65 - 85
85
Cylinder Head
Temperature
200 – 500
500
Exhaust Gas
Temperature
Fuel Quantity
Main: E = 3 gal
Aux: E = 0 gal
Main: >10
Aux: N/A
Suction / Pressure
3.75
3.75 – 5.25
5.25
Weight Limits
Maximum weight: 4200 lbs
Aft baggage limit: 400 lbs
Nose baggage limit: 270 lbs
Center of Gravity Limits
Center of gravity limits (gear extended):
Forward limit 75 inches aft of datum to gross weight of 3600 lbs, then straight-line
variation to 80.5 inches aft of datum at gross weight 4200 lbs.
Aft limit – 86 inches aft of datum at all weights
