ASSEMBLING THE BARBECUE
Tools required: Fasteners supplied:
x2
x 16
x 2
1
2
IMPORTANT
Ensure the locking type
castors are fitted to the
front of the trolley,
with locks facing outward
This hole indicates the rear side of trolley
IMPORTANT
Install with magnets facing
the front (i.e. toward the
direction
of the locking castors)
Magnets
Large head M6x12mm
M3x10mm
ASSEMBLING THE BARBECUE10
45 x large head
M6x12mm
4 x M6x20mm
2 x M3x10mm 4 x M4x8mm12 x fibre washers
