Assembly Instruction – Proline Kitchen
1. Carcass assembly
Cam lock and dowel assembly method
Side panel
Heat-resistant bracket
Divider panels
Kicker plate
Top panels
Carcass back
Turn unit right side up
Attach heat-resistant shields to carcass top
Level the cabinet by adjusting the feet
Attach base to carcass Attach carcass top
Attach side panels to back panel
Ensure the height from the ground to the top of the
carcass is minimum 735mm high in order to ensure
at least 5mm gap from the bottom of the waterfall
to the ground
