To attach the mower to be towed behind the tractor do the following:
1. Back the towing vehicle up to the mower.
2. Turn off engine and set parking break of vehicle.
3. Attach a category 1 hitch pin to towing vehicle drawbar.
4. Slide a rubber washer and mower swivel hitch on the hitch pin and secure with a
lynch pin. Make sure hitch pin goes completely through each piece and is secured to
prevent accidental separation.
5. Tighten the spring loaded nuts on the front wheels of the mower to help the unit
track behind the tractor correctly. Set for the back wheels to have some pivot to help
the mower turn with the tractor (see fig. 9).
To attach the mower to be pushed in front of the ATV/UTV do the following:
1. Secure the 2” receiver bracket to the front hitch of the ATV/UTV using the supplied
bolt. Tightening the bolt will remove any slack between the male and female part of
the receiver. This will allow for the mower to track better and remove any slack that
can be noticed when turning.
2. Turn off engine and set parking break of vehicle.
OPERATION 15 BEFCO
C
YCLONE OPERATOR’S MANUAL
Fig. 7 - Unit when rear mounted.
tractor
ATV / UTV
Fig. 8 - Unit when front mounted.
tractor
ATV / UTV
