Each C30-CE5H is supplied standard with the necessary tools to raise the deck (see
fig. 5). The height adjustment stand connected to the drawbar will allow you to raise
one side of the deck at a time to adjust the wheels to the desired cutting height (see fig.
6).
3.05 - Pre-Operational Check
IMPORTANT: Check each of the following, carefully, prior to engaging the equipment:
1. The spindle bearings have been greased.
2. The belts for proper tension.
3. No wrappings or foreign objects are around the blades or belts.
4. The blades are properly installed and the blade bolts properly torqued
4
.
5. All hardware is tight.
6. All safety shields and guards are in place and tightly attached.
7. No people or animals are in the work area.
WARNING: Shut off mower engine and remove spark plug wire from spark plug
before making adjustments, servicing or cleaning the machine. Failure to do so
could result in accidental starting of engine causing possible injury or death.
3.06 - Attaching to the Vehicle
The hitch on the C30-CE5H allows the mower to be set up to be either towed behind the
vehicle or pushed in front of the vehicle.
OPERATION 14 BEFCO
C
YCLONE OPERATOR’S MANUAL
4
See Table 1, page 29.
Fig. 5 - Mower lifiting tool.
drawbar
height adjustment
stand
Fig. 6 - Raising the mower to adjust cutting height.
