WARNING: Do not substitute blades or any bolt for the blade retaining bolt.
Company blades and blade retaining bolts are specially made for this application.
Using non original parts can effect the quality of cut and may also cause damage
to the mower.
DANGER: Proper torque must be used when tightening the blade retaining bolt. If
these safety precautions are not followed, the blade could come off during
operation and be thrown hundreds of feet from the mower.
Sharpening Blades
Blade sharpening is extremely important in order to get the best cutting results. Sharp
blades permit a high quality cut.
To sharpen blades, first remove them following the above instructions.
Place the blade in a vise and sharpen them by using a hand file or grinder. Do not
sharpen the blades to a sharp cutting edge. The cutting edge should be between
1
/
64
”
to
1
/
32
” to prevent excessive pitting and dulling of the blades. Sharpen both ends of the
blade equally for balance and always maintain corners. Always keep all three blades
sharpened equally in order to maintain balance.
CAUTION: Unbalanced or warped blades can cause damage to the mower and/or
personal injury. Replace damaged blades before operating the mower. Sharpen
both ends of the mower blades equally or until the blade is balanced.
4.04 - Belt Tension
The C30-CE5H mower is equipped with two belts, a main drive belt that runs from the
centrifugal clutch to the center spindle pulley and a secondary belt that runs between
the 3 pulleys.
Belt tension control
1. Check the main drive belt by applying a force of 3-4 lb. pushing against the belt
halfway between the centrifugal clutch and the center spindle pulley. The belt
deflection should be between
1
/
8
”-
1
/
4
”.
2. Check the secondary belt tension by applying a force of 12-15 lb. pushing against
the belt halfway between the pulleys. The belt deflection should be between
5
/
16
”-
3
/
8
”.
MAINTENANCE 26 BEFCO
C
YCLONE OPERATOR’S MANUAL
