BEFCO CYCLONE - Page 25

MAINTENANCE 25 BEFCO
C
YCLONE OPERATOR’S MANUAL
Fig. 14 - Spindle assembly.
1
3
5
7
8
9
2
4
6
10
11
1. grease fitting
2. hexagonal nut
3. pulley
4. rotor support
5. cover
6. shaft
7. blade
8. cup washer
9. blade bolt
10. cutting edge close to ground
11. lift wing
Ground
1
2
3
Fig. 15
1. spindle
2. blade
3. blade bolt
