To replace a tine do the following:
1. Remove the bolt M14x40 and the nut M14 holding the tine that needs replacing.
2. Remove tine clip and tine and replace new tine making sure to assemble it so the
tine is leading the arm when operating (see fig. 19).
3. Replace the bolt M14x40 and nut M14 and tighten
10
.
5.03 - Suggested Spare Parts
It is suggested that the following spare parts be kept on hand for the tedder at all times
to prevent a minor problem from delaying work.
2Tine arms
1 setTines
QuantityDescription
5.04 - Storage
After seasonal use it is important to perform the following for prolonged storage:
1. Wash the tedder carefully.
2. Inspect the tedder and replace worn or damaged parts.
3. Tighten all hardware.
4. Grease all areas indicated under Maintenance
11
.
5. Cover the tedder from the elements in order to have it in perfect condition for the
start of the next season.
6. Do not permit children to play on or around the stored unit.
7. Do not park or store equipment where it will be exposed to livestock for long periods
of time. Damage and livestock injury could result.
8. Make sure all parked machines are on a hard, level surface, and engage all safety
devices.
WARNING: Be sure to store the implement on a hard level surface and away from
people especially children.
REPAIR PROCEDURES 32 BEFCO
R
OTARY TEDDERS OPERATOR’S MANUAL
11
See Chapter 4 - Maintenance.
10
See Table 1, page 30.
