Fundor T
7
Installation
Only a trained worker is allowed to install
the Fundor T.
Observe the safety information!
l Place the Fundor T on a level worktop. Fundor T
has to contact the working bench with all four feet.
The front right rubber foot can be used for levelling
- after opening side panel (see figure 1).
l There is the possibility to screw on two feet. Open
the right-hand side panel and unscrew the two
rubber feet. Fasten the separately delivered feet and
mark the fixing points at the bench. Drill holes in
the worktop and screw the casting machine down
with suitable screw (see figure 2).
l Install the Multiplex melting torch next to the
machine in a suitable position.The automatic
gas lighter facilities enormously the firing and
adjustingof the melting torch. It can be mounted at
the wall or at the back of Fundor T (pos. 7 in fig. 4).
When installing these units take notice of their
instructions for use.
Fig. 1 Fig. 2
