Page #4 background imageLoading...
Page #4 background image
4 SINGLE DIAPHRAGM CONDENSER MICROPHONE B-1 User Manual
Specications5.
Transducer type condenser, 1" single diaphragm
Operating principle pressure gradient
Polar pattern cardioid
Connection gold-plated balanced XLR connector
Open circuit voltage at 1 kHz -34 +/-2 dBV (0 dBV = 1 V/Pa)
Open circuit sensitivity 20 mV/Pa
Frequency range 20 Hz - 20 kHz
Level attenuation -10 dB (switchable)
Low-Cut lter 6 dB/Octave at 75 Hz (switchable)
Max. SPL (1% THD @ 1 kHz) 138 dB (0 dB), 148 dB (-10 dB)
Equivalent SPL (IEC 268-4) 13 dB-A
Signal-to-noise ratio re 1 Pa 81 dB A-weighted
Nominal impedance 50 Ω
Load impedance > 1 kΩ
Mains Voltage/Fuse
Supply voltage +48 V
Supply current 3 mA
Physical/Weight
Dimensions : 58 mm, length: 174 mm
Weight 0,461 kg

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Behringer B-1 and is the answer not in the manual?

Behringer B-1 Specifications

General IconGeneral
TypeStudio microphone
Microphone frequency20 - 20000 Hz
Microphone direction typeCardioid
Microphone operation modePressure gradient
Microphone input impedance50 Ω
Device interfaceXLR-3
Operating frequency20 - 20000 MHz
Connectivity technologyWired
Operating voltage48 V
Power consumption3 mA
Number of products included1 pc(s)
Depth (imperial)6.8 \
Height (imperial)2.2 \
On/off switchYes
Product color-
Signal-to-Noise Ratio (SNR)81 dB
Weight and Dimensions IconWeight and Dimensions
Depth174 mm
Height58 mm
Microphone weight450 g
Microphone dimensions (D x H)174 x 58 mm
