Behringer B-5 Technical Specifications

2 SINGLE DIAPHRAGM CONDENSER MICROPHONE B-5 Technical Specifications
SINGLE DIAPHRAGM CONDENSER
MICROPHONE B-5
Gold-Sputtered Diaphragm Studio Condenser Microphone with
2 Interchangeable Capsules
Professional gold-sputtered diaphragm condenser microphone for unsurpassed audio quality
Ideal as main and support microphone for studio and live applications—perfect for acoustic instruments and overhead etc.
2 interchangeable capsules with cardioid and omnidirectional pickup patterns
Pressure-gradient transducer with shock-mounted gold-sputtered diaphragm capsule
Switchable low-frequency roll-o and input attenuation
Ultra low-noise transformerless FET input eliminates low-frequency distortion
Gold-plated 3-pin XLR output connector for highest signal integrity
Rugged construction with satin nickel-plated brass body
Stand adapter, windscreen and transport case included
High-quality components and exceptionally rugged construction ensure long life
Conceived and designed by BEHRINGER Germany
0 dB
-5 dB
-10 dB
-15 dB
-20 dB
-25 dB
-30 dB
180˚
150˚
120˚
90˚
60˚
30˚
210˚
240˚
270˚
300˚
330˚
0˚
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
8000 Hz
16000 Hz
Polar pattern (cardioid)
dB
20.0
10.0
-10.0
-20.0
50.0 100.0
Low cut
1000.0 10k 15k 20k Hz
0.0
Frequency response (cardioid)
0 dB
-5 dB
-10 dB
-15 dB
-20 dB
-25 dB
-30 dB
180˚
150˚
120˚
90˚
60˚
30˚
210˚
240˚
270˚
300˚
330˚
0˚
250 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
8000 Hz
16000 Hz
Polar pattern (omnidirectional)
Frequency response (omnidirectional)
dB
20.0
10.0
-10.0
-20.0
50.0 100.0
Low cut
1000.0 10k 15k 20k Hz
0.0

Behringer B-5 Specifications

Microphone Specifications

transducer type	true condenser
diaphragm size	18 mm (0.71") single diaphragm
polar pattern	1 x cardioid, 1 x omnidirectional, exchangeable

Sensitivity and Frequency

open circuit sensitivity (cardioid)	-38 dBV (0 dBV = 1 V/Pa), 12.6 mV/Pa
open circuit sensitivity (omnidirectional)	-40 dBV (0 dBV = 1 V/Pa), 10 mV/Pa
frequency response	20 Hz - 20 kHz

Sound Pressure Levels

max SPL (1% THD @ 1 kHz)	140 dB (0 dB), 150 dB (-10 dB)
equivalent SPL (cardioid)	16 dB-A
equivalent SPL (omnidirectional)	18 dB-A

Electrical Characteristics

nominal impedance	70 Ω
load impedance	>1 kΩ
supply voltage	+48 V

Physical Characteristics

dimensions	Ø shaft: 20 mm / Length: 120 mm
weight	approx. 0.21 lbs / 0.09 kg
supply current	3 mA
