Behringer B-5 Technical Specifications

3 SINGLE DIAPHRAGM CONDENSER MICROPHONE B-5 Technical Specifications
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time to time to existing products without prior notice. Specifications and appearance may differ from those
listed or illustrated.
TECHNICAL SPECIFICATIONS AND APPEARANCES ARE SUBJECT TO CHANGE WITHOUT NOTICE AND ACCURACY IS NOT GUARANTEED. BEHRINGER IS PART OF THE MUSIC GROUP (MUSIC-GROUP.COM). THE INFORMATION CONTAINED HEREIN IS CORRECT
AT THE TIME OF PRINTING. ALL TRADEMARKS ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS. MUSIC GROUP ACCEPTS NO LIABILITY FOR ANY LOSS WHICH MAY BE SUFFERED BY ANY PERSON WHO RELIES EITHER WHOLLY OR IN PART UPON ANY
DESCRIPTION, PHOTOGRAPH OR STATEMENT CONTAINED HEREIN. COLORS AND SPECIFICATIONS MAY VARY FROM ACTUAL PRODUCT. MUSIC GROUP PRODUCTS ARE SOLD THROUGH AUTHORIZED FULLFILLERS AND RESELLERS ONLY. FULLFILLERS AND
RESELLERS ARE NOT AGENTS OF MUSIC GROUP AND HAVE ABSOLUTELY NO AUTHORITY TO BIND MUSIC GROUP BY ANY EXPRESS OR IMPLIED UNDERTAKING OR REPRESENTATION. THIS MANUAL IS COPYRIGHTED. NO PART OF THIS MANUAL MAY BE
REPRODUCED OR TRANSMITTED IN ANY FORM OR BY ANY MEANS, ELECTRONIC OR MECHANICAL, INCLUDING PHOTOCOPYING AND RECORDING OF ANY KIND, FOR ANY PURPOSE, WITHOUT THE EXPRESS WRITTEN PERMISSION OF MUSIC GROUP IP LTD. ALL
RIGHTS RESERVED. © 2011 MUSIC GROUP IP LTD. TRIDENT CHAMBERS, WICKHAMS CAY, P.O. BOX 146, ROAD TOWN, TORTOLA, BRITISH VIRGIN ISLANDS
Specications
Transducer type true condenser,
18 mm (0.71") single diaphragm
Operating Principle
Cardioid pressure gradient
Omnidirectional pressure operated
Polar pattern 1 x cardioid
1 x omnidirectional, exchangeable
Connection gold-plated balanced XLR connector
Open Circuit Sensitivity (at 1 kHz)
Cardioid -38 dBV (0 dBV = 1 V/Pa), 12.6 mV/Pa
Omnidirectional -40 dBV (0 dBV = 1 V/Pa), 10 mV/Pa
Frequency response 20 Hz - 20 kHz
Level attenuation -10 dB (switchable)
Low-cut lter 6 dB/oct. at 150 Hz (switchable)
Max. SPL (1% THD @ 1 kHz) 140 dB (0 dB), 150 dB (-10 dB)
Equivalent SPL (IEC 651) 16 dB-A (cardioid), 18 dB-A (omnidir.)
Signal-to-Noise Ratio
Cardioid 78 dB A-weighted
Omnidirectional 76 dB A-weighted
Nominal impedance 70 Ω
Load impedance >1 kΩ
Mains Voltage/Fuse
Supply voltage +48 V
Supply current 3 mA
Physical/Weight
Dimensions Ø shaft: 20 mm / Length: 120 mm
Weight approx. 0.21 lbs / 0.09 kg

Behringer B-5 Specifications

Microphone Specifications

transducer type	true condenser
diaphragm size	18 mm (0.71") single diaphragm
polar pattern	1 x cardioid, 1 x omnidirectional, exchangeable

Sensitivity and Frequency

open circuit sensitivity (cardioid)	-38 dBV (0 dBV = 1 V/Pa), 12.6 mV/Pa
open circuit sensitivity (omnidirectional)	-40 dBV (0 dBV = 1 V/Pa), 10 mV/Pa
frequency response	20 Hz - 20 kHz

Sound Pressure Levels

max SPL (1% THD @ 1 kHz)	140 dB (0 dB), 150 dB (-10 dB)
equivalent SPL (cardioid)	16 dB-A
equivalent SPL (omnidirectional)	18 dB-A

Electrical Characteristics

nominal impedance	70 Ω
load impedance	>1 kΩ
supply voltage	+48 V

Physical Characteristics

dimensions	Ø shaft: 20 mm / Length: 120 mm
weight	approx. 0.21 lbs / 0.09 kg
supply current	3 mA
