B-CONTROL FADER BCF2000/B-CONTROL ROTARY BCR2000

USB-Mode U-4 (expanded):

Fig. 4.4: Application in USB mode 4 (expanded)

4. CONTROLS

Fig. 4.5: Routing in USB mode 4

This operating mode should be selected if you want to couple

two B-CONTROLs (e.g. 1x BCF2000 & 1x BCR2000) to control

your software using both B-CONTROLS through a common USB

port. Additionally, MIDI OUT B of the first controller (unit 1) can

be used from the computer as a 16-channel MIDI output. The

data of both B-CONTROLs is mixed and is sent to the host

computer via USB. Select stand-alone mode 3 for the second

unit (unit 2).

4.1.2 Stand-alone modes

The stand-alone modes come into play when the B-CONTROL

is not used as a USB-controller for controlling PC applications

but as a pure MIDI controller. With all stand-alone modes, all

MIDI connectors can be used simultaneously, and these modes

differ only in how the data is transmitted on the MIDI outputs. Of

course, not only sound generators can be remotely controlled

(as shown in the illustrations) but also effects processors, groove

boxes, hardware sequencers, lighting equipment, compact

studios, portable keyboards, e-pianos etc.  basically any

equipment with a MIDI input. This can also be your computer

with its own MIDI interface. The USB connector can not be used

while your B-CONTROL is in one of the stand-alone modes. A

merge function that makes mixing MIDI data from two different

sources to one output possible is active at output A in all stand-

alone modes.
