Specifications
Outputs
CV
Type
2 x 3.5 mm TS jack,
DC coupled
Impedance 100 Ω
Max output level -6.3 V to +10 V
CV range,
System 100,
2500 series mode
-1 V to +9 V,
1 V/octave
CV range, System
15, 35, 55 mode
-5.3 V to +4.7 V,
1 V/octave
CV modes output
Trig
Type
2 x 3.5 mm TS jack,
DC coupled
Impedance 25 Ω
Max output level
+5 V when in
V-Trig mode, S-Trig
= pull down to 0 V
Trig modes
V-Trig, S-Trig, both:
upper = S-Trig,
lower = V-Trig
MIDI
Type
2 x 5-pin DIN
MIDI IN and
MIDI THRU
MIDI Channel
(1 to 16) set via
SynthTribe tool
USB
Type USB 2.0, Type B
Mode select (rear panel)
Mode 1, underside
LEDs = red/red
System 15, 35, 55
CV range,
monophonic
Mode 2, underside
LEDs = green/red
System 100, 2500
series CV range,
monophonic
Mode 3, underside
LEDs = red/green
System 15, 35, 55
CV range,
duophonic
Mode 4, underside
LEDs = green/
green
System 100, 2500
series CV range,
duophonic
Power
Power supply Eurorack
Current draw
70 mA (+12 V),
10 mA (-12 V)
Physical
Dimensions
30 x 129x 520 mm
(1.18 x 5.08 x
20.47")
Rack units 6 HP
Weight 0.09 kg (0.19 lbs)
45Quick Start Guide44 CM1A
