Behringer EUROCOM AX6220 Specifications

3
Energy-Efficient, DSP-Powered and Ethernet/USB-Controlled
2900/2000-Watt Low-Impedance amplifier
AX6240/AX6220
Power Output LO-Z AX6220 AX6240
Peak, 1% THD, 1 kHz sine wave
Stereo (both channels driven)
• 8 Ω per channel 480 W 680 W
• 4 Ω per channel 900 W 1300 W
• 2 Ω per channel 1400 W 2250 W
Bridged mono
• 8 Ω 1750 W 2560 W
• 4 Ω 2600 W 4000 W
RMS, 1% THD, 1 kHz sine wave
Stereo (both channels driven)
• 8 Ω per channel 400 W 550 W
• 4 Ω per channel 650 W 900 W
• 2 Ω per channel 1000 W 1500 W
Bridged mono
• 8 Ω 1300 W 1850 W
• 4 Ω 2000 W 2900 W
Audio Inputs / Outputs
• Line level inputs 2 x 3-pin Euroblock and XLR /
TRS combo
• Input impedance 10 kΩ unbalanced, 20 kΩ balanced
• Input sensitivity 1 V @ 4 Ω 1 V @ 4 Ω
• Input clipping 11 Vrms 11 Vrms
(+23 dBu) (+23 dBu)
• Overall system gain @ 8 Ω 34 dB (AX6220) 36dB
• Outputs Binding posts and NL-4
• Output circuit type Class H Class H
• Minimum load impedance 2 Ω 2 Ω
System Information AX6220 AX6240
• Frequency response 20 Hz – 20 kHz, +0 / -1 dB @ 1 W,
1 kHz dBr into 8 Ω load
• THD+N < 0.25% @ 1 W, 1 kHz dBr into
8 Ω load
• Signal-to-noise ratio 87 dB (@ input 2 dBu) 93 dB
(@ +22 dBu)
• Damping factor > 220 @ 8 Ω > 220 @ 8 Ω
• Crosstalk > -70 dB @ rated > -68 dB @ rated
power, 1 kHz power, 1 kHz
• Indicators Power indicator LED ring illumination
(yellow) Overload/Protection LED ring
(red) LCD display VU meters, system fault,
overcurrent / overdrive indicators
• Operating temperature 14° F to 104° F 14° F to 104° F
(-10° C to +40° C) (-10° C to +40° C)
• Cooling method Automatic variable speed fan rear to
front airow
Digital Signal Processing (DSP)
• PC control Type B USB on front or IEEE 802.3
Ethernet network connector on back panel
• Display LCD 128 x 32, amber backlit
• Digital delay function 0 – 300 ms 0 – 300 ms
• Digital crossover function 3 lter types, (Butterworth, Bessel,
(per channel) Linkwitz-Riley) up to
48 dB/octave
• Digital EQ function 8-band parametric, 2-band dynamic
(per channel) equalizer
• Digital dynamics function Zero attack limiter Zero attack limiter
(per channel)
• Presets 20 total presets, 19 user-denable
Power Supply AX6220 AX6240
• Power consumption 7A @ 220-240 V~ 5A @ 220-240 V~
50/60 Hz; 50/60 Hz;
12A @ 120 V~ 9A @ 120 V~
60 Hz; 60 Hz;
14A @ 100 V~ 10A @ 100 V~
50/60 Hz 50/60 Hz
• Power eciency 69% 69%
• AC power source 100~120 V AC 50/60 Hz
220~240 V AC 50/60 Hz
Dimensions / Weight
• Dimensions (H x W x D) 3.5 x 19 x 16" / 95 x 483 x 408 mm
3.7 x 17 x 16" / 95 x 432 x 406 mm
• Weight 21.6 lbs / 9.8 kg (AX6240)
21.4 lbs/ 9.7 kg
Materials
• Case material Cold-rolled steel
• Face plate material Perforated steel
• Included accessories Rack mount bracket
