Energy-Eﬃcient, DSP-Powered and Ethernet/USB-Controlled

2900/2000-Watt Low-Impedance ampliﬁer

AX6240/AX6220

Summary description:TheampliershallbeofClassHdesignwithanenergy-ecientswitch-modepowersupplyandshall

providetwolow-impedanceoutputchannelsina2Urack-mountablefan-cooledchassiswithintegratedDSPandremote

Ethernet/USBcontrol.

Digitalsignalprocessing(DSP)incorporatedintotheampliershallincludedelay,crossover,dynamics,parametricEQ

(8-band),anddynamicEQ(2-band).Theamplier'sA/DandD/Aconvertersshallbe24-bit/96kHz.

Controls and indicatorsshallincludethefollowing:

• MasterEncoderknobforsettingvolumeandDSPparameters

• Indicatorringforpower(yellow)andclipping(ashingred)

• LCDscreentodisplaycurrentDSPmoduleandsettings

• UpandDownbuttonstoselectDSPmodulesandparameters

• ProcessbuttontoselectDSPprocessingmodules

• SetupbuttontoselectDSPparameters

• Exitbuttontodisplaythetop-levelDSPmenu

• ACpowerswitchonrear-paneltoturnamplieron/o

Connectionstotheampliershallincludethefollowing:

• Remotepoweron/oon2-pinEuroblocksocket

• InputsAandB,balancedorunbalancedmicorline-level,onXLR/TRScombinationjacksandon3-pinEuroblocksockets

• OutputsonNL4panelconnectors(twist-lock)andonbindingposts(barewireorbananaplugs)

• EthernetonRJ45jackforLANconnection

• USBjackforconnectingacomputer

• ACpoweronIECconnector

Cooling and protectionshallincludeback-to-frontventilationprovidedbydualvariable-speedfans.Eachamplieroutput

channelshallbeprotectedagainstoverloadbyalimiter.EachamplieroutputchannelshallincorporateindependentDC

andthermaloverloadprotection.

Architect’s and Engineer’s Specications
