Behringer EUROCOM AX6220 User Manual

Specications
AX6240 AX6220
Power Output LO-Z
Peak, 1% THD, 1 kHz Sine Wave
Stereo (both channels driven)
8  per channel 700 W 480 W
4  per channel 1300 W 900 W
2  per channel 2250 W 1400 W
Bridged mono
8  2550 W 1750 W
4  4050 W 2600 W
RMS, 1% THD, 1 kHz Sine Wave
Stereo (both channels driven)
8  per channel 550 W 400 W
4  per channel 910 W 650 W
2  per channel 1500 W 1000 W
Bridged mono
8  1850 W 1300 W
4  3000 W 2000 W
Audio Inputs / Outputs
Line level inputs 2 x 3-pin Euroblock and XLR / TRS combo 2 x 3-pin Euroblock and XLR / TRS combo
PC control Type B USB on front or IEEE 802.3 Ethernet network connector on back panel
Input impedance 10 k unbalanced, 20 k balanced 10 k unbalanced, 20 k balanced
Input sensitivity 1 V @ 4  1 V @ 4 
Input clipping 11 Vrms (+23 dBu) 11 Vrms (+23 dBu)
Overall system gain @ 8  36 dB 34 dB
Outputs Binding posts and NL-4 Binding posts and NL-4
Output circuit type Class H Class H
Minimum load impedance 2  2 
System Information
Frequency response
20 Hz – 20 kHz, +0 / -1 dB @ 1 W,
1 kHz dBr into 8  load
20 Hz – 20 kHz, +0 / -1 dB @ 1 W,
1 kHz dBr into 8  load
THD + N < 0.25% @ 1 W, 1 kHz dBr into 8  load < 0.25% @ 1 W, 1 kHz dBr into 8  load
Signal-to-noise ratio
87 dB (@ input 2 dBu)
93 dB (@ +22 dBu)
87 dB (@ input 2 dBu)
93 dB (@ +22 dBu)
Damping factor > 220 @ 8  > 220 @ 8 
Crosstalk > -70 dB @ rated power, 1 kHz > -68 dB @ rated power, 1 kHz
Indicators
Power indicator LED ring illumination (yellow)
Overload/Protection LED ring (red)
LCD display with VU meters, system fault, overheating, overcurrent / overdrive indicators
Operating temperature 14° F to 104° F (-10° C to +40° C) 14° F to 104° F (-10° C to +40° C)
Cooling method Automatic variable speed fan Automatic variable speed fan
AX6240 AX6220
Digital Signal Processing (DSP)
Display LCD 128 x 32, amber backlit
Digital delay function (per channel) 0 – 300 ms
Digital crossover function 3 lter types, up to 48 dB/octave
Digital EQ function (per channel) 8-band parametric, 2-band dynamic equalizer
Digital dynamics function (per channel) Zero attack limiter
Presets 20 total presets, 19 user-denable
Power Supply
Power consumption
7A @ 220-240 V~ 50/60 Hz; 12A @ 120 V~ 60 Hz;
14A @ 100 V~ 50/60 Hz
5A @ 220-240 V~ 50/60 Hz; 9A @ 120 V~ 60 Hz;
10A @ 100 V~ 50/60 Hz
Power eciency 69%
AC power source
100 V~ 50/60 Hz; 120 V~ 60 Hz;
220-240 V~ 50/60 Hz
Dimensions / Weight
Dimensions (H x W x D) appr. 3.74 x 19 x 16" / 95 x 483 x 408 mm appr. 3.74 x 19 x 16" / 95 x 483 x 408 mm
Weight appr. 21.6 lbs / 9.8 kg appr. 21.4 lbs / 9.7 kg
Materials
Case material Cold-rolled steel Cold-rolled steel
Face plate material Perforated steel Perforated steel
Included accessories Rack mount brackets Rack mount brackets
28 29Quick Start GuideEUROCOM AX6240/AX6220
