Specications Especicaciones técnicas
AX6240Z AX6220Z
Power Output HI-Z
Peak, 1% THD, 1 kHz Sine Wave
Stereo (both channels driven)
70 V 900 W @ 7 Ω 500 W @ 14 Ω
100 V 1300 W @ 10 Ω 700 W @ 20 Ω
RMS, 1% THD, 1 kHz sine wave
Stereo (both channels driven)
70 V 700 W @ 7 Ω 350 W @ 14 Ω
100 V 1000 W @ 10 Ω 500 W @ 20 Ω
Audio Inputs / Outputs
Line level inputs 2 x 3-pin Euroblock and XLR / TRS combo
PC control Type B USB on front or IEEE 802.3 Ethernet network connector on back panel
Input impedance 10 kΩ unbalanced, 20 kΩ balanced
Input sensitivity 1 V @ 10 Ω 1 V @ 20 Ω
Input clipping 11 Vrms (+23 dBu)
Overall system gain @ 10 Ω 37 dB (70 V) / 40 dB (100 V)
Outputs 4-position barrier strip
Output circuit type Class D
Minimum load impedance 7 Ω (70 V) / 10 Ω (100 V) 14 Ω (70 V) / 20 Ω (100 V)
System Information
Frequency response
30 Hz – 20 kHz (-0.3 / -2 dB) (70 V)
30 Hz – 20 kHz (-0.3 / -1 dB) (100 V)
THD+N < 0.25% @ 1 W, 1 kHz into 7 Ω load < 0.25% @ 1 W, 1 kHz into 14 Ω load
Signal-to-noise ratio 87 dB (@ input 2 dBu) 93 dB (@ +22 dBu)
Damping factor > 200 @ 62 Ω
Crosstalk > 70 dB below rated power, 1 kHz > 68 dB below rated power, 1 kHz
Indicators
Power indicator LED ring illumination (yellow)
Overload/Protection LED ring (red)
LCD display with VU meters, system fault, overheating, overcurrent / overdrive indicators
Operating temperature 14° F to 104° F (-10° C to +40° C)
Cooling method Automatic variable speed fan
Digital Signal Processing (DSP)
Display LCD 128 x 32, amber backlit
Digital delay function (per channel) 0 – 300 ms
Digital crossover function 3 lter types, up to 48 dB/octave
Digital EQ function (per channel) 8-band parametric, 2-band dynamic equalizer
Digital dynamics function (per channel) Zero attack limiter
Presets 20 total presets, 19 user-denable
Power Supply
Power consumption 260 W 230 W
Power eciency 84%
AC power source
100 V AC 50/60 Hz
120 V AC 60 Hz
220-240 V AC 50/60 Hz
Dimensions / Weight
Dimensions (H x W x D) appr. 95 x 483 x 390 mm (3.74 x 19.01 x 15.35") appr. 95 x 483 x 390 mm (3.74 x 19.01 x 15.35")
Weight appr. 8.58 kg (18.91 lbs) appr. 8.1 kg (17.85 lbs)
Materials
Case material Cold-rolled steel
Face plate material Perforated steel
Included accessories Rack mount brackets
AX6240Z AX6220Z
Potencia de Salida HI-Z
Picos 1% THD, Onda Sinusoidal 1 kHz
Stereo (ambos canales con señal)
70 V 900 W @ 7 Ω 500 W @ 14 Ω
100 V 1300 W @ 10 Ω 700 W @ 20 Ω
RMS, 1% THD, Onda Sinusoidal 1 kHz
Stereo (ambos canales con señal)
70 V 700 W @ 7 Ω 350 W @ 14 Ω
100 V 1000 W @ 10 Ω 500 W @ 20 Ω
Entradas/Salidas Audio
Entradas de nivel de línea 2 x Euroconector de 3 puntas y combo XLR / TRS
Control PC USB tipo B en panel frontal y conector de red Ethernet IEEE 802.3 en panel trasero
Impedancia de entrada 10 kΩ no balanceado, 20 kΩ balanceado
Sensibilidad de entrada 1 V @ 10 Ω 1 V @ 20 Ω
Saturación de entrada 11 Vrms (+23 dBu)
Ganancia general del sistema @ 10 Ω 37 dB (70 V) / 40 dB (100 V)
Salidas Tope de 4 posiciones
Tipo de circuito de salida Clase D
Impedancia de carga mínima 7 Ω (70 V) / 10 Ω (100 V) 14 Ω (70 V) / 20 Ω (100 V)
Información del Sistema
Respuesta de frecuencia
30 Hz – 20 kHz (-0.3 / -2 dB) (70 V)
30 Hz – 20 kHz (-0.3 / -1 dB) (100 V)
THD+N < 0.25% @ 1 W, 1 kHz con carga de 7 Ω < 0.25% @ 1 W, 1 kHz con carga de 14 Ω
Relación señal-ruido 87 dB (@ input 2 dBu) 93 dB (@ +22 dBu)
Factor de amortiguación > 200 @ 62 Ω
Crosstalk o cruce de señal > -70 dB @ potencia media, 1 kHz > -68 dB @ potencia media, 1 kHz
Indicadores
Anillo de pilotos LED indicador de encendido (amarillo)
Anillo de pilotos LED de sobrecarga/protección (rojo)
Pantalla LCD con medidores VU e indicadores de fallo del sistema, recalentamiento y pico de corriente / saturación
Temperatura de funcionamiento -10º a +40° C (14° a 104° F) -10° a +40° C (14° a 104° F)
Sistema de refrigeración Ventilador con velocidad variable de ajuste automático
Procesado Digital de Señal (DSP)
Pantalla LCD 128 x 32, color ámbar y retroiluminada
Función de retardo digital (por canal) 0 – 300 ms
Función de crossover digital 3 tipos de ltro, hasta 48 dB/octava
Función de EQ digital (por canal) ecualizador paramétrico de 8 bandas, dinámico de 2 bandas
Función de dinamismo digital (por canal) limitador con ataque cero
Presets 20 presets en total, 19 de ellos programables por el usuario
Fuente de Alimentación
Consumo 260 W 230 W
Eciencia 84%
Fuente de alimentación CA
100 V AC 50/60 Hz
120 V AC 60 Hz
220-240 V AC 50/60 Hz
Dimensiones / Peso
Dimensiones (A x L x P) aprox. 95 x 483 x 390 mm (3,74 x 19,01 x 15,35") aprox. 95 x 483 x 390 mm (37.4 x 19,01 x 15,35")
Peso aprox. 8,58 kg (18,91 lbs) aprox. 8,1 kg (17,85 lbs)
Materiales
Carcasa Acero corrugado
Panel frontal Acero perforado
Accesorios incluidos Abrazaderas de montaje en rack
20 21Quick Start GuideEUROCOM AX6240Z/AX6220Z
