25
EURORACK MX2004A
9. SPECIFICATIONS
Mono input channels
Mic input electronically balanced, discrete input configuration
Frequency response 10 Hz to 60 kHz, +/- 3 dB
Distortion (THD & N) 0.007% @ +4 dBu, 1 kHz, bandwidth 80 kHz
Mic E.I.N. (22 Hz - 22 kHz) -129.5 dBu, 150 Ohm source
-117.3 dBqp, 150 Ohm source
-132.0 dBu, input shorted
-122.0 dBqp, input shorted
Gain range +10 dB to +60 dB
Signal-to-noise ratio 113,6 dB
Line input electronically balanced
Frequency response 10 Hz to 60 kHz, +/- 3 dB
Distortion (THD & N) 0.007% @ +4 dBu, 1 kHz, bandwidth 80 kHz
Gain range +10 dBu to -40 dBu
EQ
Low 80 Hz, +/- 15 dB, Q=2
Mid 100 Hz to 8 kHz, +/- 15 dB, Q=1
High 12 kHz, +/- 15 dB, Q=2
Stereo input channels
Line input unbalanced
Frequency response 10 Hz bis 55 kHz, +/- 3 dB
Distortion (THD & N) 0.007% @ +4 dBu, 1 kHz, bandwidth 80 kHz
EQ
Low 80 Hz, +/- 15 dB, Q=2
Low Mid 500 Hz, +/- 15 dB, Q=2
Hi Mid 3 kHz, +/- 15 dB, Q=2
High 12 kHz, +/- 15 dB, Q=2
Main mix
Max. output +28 dBu, balanced, XLR
+22 dBu, unbalanced, 1/4" phone connectors
Aux Sends max. output +22 dBu, unbalanced
Signal-to-noise ratio 112 dB
Noise (absolute) bus noise, fader 0 dB, channels muted:
-100.0 dBr (ref.: +4 dBu)
fader 0 dB, all input channels assigned and set to unity gain:
-88.5 dBr (ref.: +4 dBu)
Power supply
Mains voltage U.S.A./Canada 115 V ~, 60 Hz, power supply MXUL1
U.K./Australia 240 V ~, 50 Hz, power supply MXUK1
Europe 230 V ~, 50 Hz, power supply MXEU1
Japan 100 V ~, 60 Hz, power supply MXJP1
Physical
Dimensions (H * W * D) app.1½"/3½" (40/90 mm) x 16¼" (410 mm) x 15¼" (385 mm)
Net weight app. 6 kg (PSU not included)
Total weight app. 8 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made
from time to time to existing products without further notice. Specifications and appearance may differ from those listed or illustrated.
