7. APPENDIX
7.1 Specifications
Mono Inputs
Mic Input electronically balanced, discrete input configuration
Bandwidth 10 Hz to 60 kHz ± 3 dB
Distortion (THD&N) 0.007% at +4 dBu, 1 kHz, Bandwidth 80 kHz
Mic E.I.N. (22 Hz - 22 kHz) -129.5 dBu, 150 Ohm source
-117.3 dBqp, 150 Ohm source
-132.0 dBu, input shorted
-122.0 dBqp, input shorted
Gain range +10 dB to +60 dB
Line Input electronically balanced
Bandwidth 10 Hz to 60 kHz ± 3 dB
Distortion (THD&N) 0.007% at +4 dBu, 1 kHz, Bandwidth 80 kHz
Line level range +10 dBu to -40 dBu
Equalization
Hi Shelving 12kHz +/-15 dB
Mid Range 2.5 kHz +/-15 dB
Lo Shelving 80Hz +/-15 dB
Stereo inputs
Line Input unbalanced
Bandwidth 10 Hz to 55 kHz ± 3 dB
Distortion (THD&N) 0.007% at +4 dBu, 1 kHz, Bandwidth 80 kHz
Equalization
Hi Shelving 12kHz +/-15 dB
Mid Range 2.5 kHz +/-15 dB
Lo Shelving 80Hz +/-15 dB
Main Mix section
Max Output +22 dBu balanced
Aux Send Max Out +22 dBu unbalanced
Control Room Out +22 dBu unbalanced
Signal-To-Noise Ratio 112 dB, all channels at Unity Gain
Power supply
Mains Voltages USA/Canada ~ 115 V AC, 60 Hz, power supply unit MXUL2
U.K./Australia ~ 240 V AC, 50 Hz, power supply unit MXUK2
Europe ~ 230 V AC, 50 Hz, power supply unit MXEU2
Japan ~ 100 V AC, 60 Hz, power supply unit MXJP2
Physical
(H * W * D) 20 / 35 mm * 160 mm * 210 mm
Net Weight 3,0 kg (PSU not included)
Gross Weight 4.6 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be
made from time to time to existing products without prior notice. Specifications and appearance may differ from those listed or
shown.
