Behringer FCV100 Quick Start Guide

(EN) Controls
(1) By switching into “NORM” mode,
the FCV100 is capable of controlling
the volume of two individual musical
instruments. Signals from INPUT 1/2
are led to OUTPUT 1/2. In “CV” mode
the FCV100 can control modulation
and volume levels of other musical
instruments by connecting OUTPUT
2 to the volume or modulation input
of the instrument. In “CV” mode,
whenOUTPUT2 is in use, INPUT/OUTPUT1
can still be used for controlling the
volume of another instrument, similarto
“NORM” mode. Allconnections are made
with standard ¼ "TRSplugs.
(2) In “NORM” mode, these jacks are used
to feed separate instrument inputs with
the FCV100’s input signal. If you only use
OUTPUT 2 in “CV” mode, the FCV100
functions as a CV controller.
(3) Turning the MIN VOL control fully
clockwise will increase the volume at the
minimum setting. This allows you to set
the volumerange.
(4) By using the pedal in the NORM mode,
youcontrol the volume level in both
channels. In CV mode, the pedal controls
OUTPUT 2 for a remote control of
parameters such as sound or e ects.
(5) When the battery LED indicator dims or
does not light up, youneed to replace
the battery.
(6) Connect your instruments via the
INPUTS1/2 using the “NORM” mode.
In“CV” mode, INPUT2 of your FVC100 can
not be used since the control signal comes
exclusively from OUTPUT 2. Asstated
before, you may use INPUT 1/OUTPUT 1
also in “CV” mode to control the volume
level of instruments.
(7) The FCV100 can be operated via an 12VDC
power adapter or with a 9V battery
(Type6LR91). If you use a battery and
the power adapter at the same time, the
FCV100 draws no power from the battery.
NORMCV
(1) (2) (3) (4)
(5) (6)
(7)
FOOT CONTROLLER FCV100 Controls
12 13 Quick Start Guide
FOOT CONTROLLER FCV100
