Synthesizers and Samplers
PRO -1
Connect the negative probe of your Voltmeter to ground.
Turn o the power and unplug the power connector.
Measure the output voltage. It should read +2.000 VDC.
Make sure the internal connections are still correctly inserted and secured.
If not, then adjust the OCT ADJ potentiometer until the measured output voltage is +2.000 VDC.
Ret the top panel back into the bottom chassis and secure with all the screws.
This calibration is done after the oscillator calibration. The positions of knobs and switches are shown in red on Figure 1.
Connect a guitar tuner to the rear panel main 1/4" output.
OCTAVE Calibration (user mode)
Turn on the OSCA SAW switch.
Set the position of the OCTAVE switch to 0. On your external keyboard, press the A1 key.
Set the position of the OCTAVE switch to 3. Adjust the OCT ADJ trimmer until there are zero beats.
End of Procedure
