Behringer TD-3 User Manual

Specications
62
TD-3
Synthesizer Architecture
Number of voices Monophonic
Type Analog
Oscillators 1
VCF 1 low pass
Envelopes 1
Connectivity
Power input DC input connector
Power switch Push button on/o
MIDI In/Thru MIDI In and MIDI Thru, 5-pin DIN
USB (MIDI) USB 2.0, type B
Outputs Line output: ¼" TRS, unbalanced, max. +8 dBu
Output impedance 1.5 k
Headphones 3.5 mm TRS, max. 50 mW/32  (1 KHz, 1% THD)
Headphones output impedance 15 
USB
Type Class compliant USB 2.0, type B
Supported Operating Systems Windows 7 or higher
Mac OS X 10.6.8 or higher
Inputs and Outputs (TS 3.5 mm)
Inputs Filter in: +12 dBu
Sync in: More than: 2.5 V
Outputs CV out: +1 V to +5 V (1 volt/oct)
Gate out: OFF: 0 V; ON: +12 V
Power Requirements
External power adaptor (use only the
supplied adapter)
9 VDC 670 mA
Power consumption 2 W Maximum
Indicator Power LED
Environmental
Operating temperature range 5°C – 40°C (41°F – 104°F)
Physical
Dimensions (H x W x D) 56 x 305 x 165 mm (2.2 x 12 x 6.5")
Weight 0.8 kg (1.8 lbs)
Shipping weight 1.4 kg (3.1 lbs)

Behringer TD-3 Specifications

General

Product type	Analog synthesizer
Product color	Red
Keyboard number of keys	-
MIDI in	Yes
USB ports quantity	1
Package weight	1400 g
DC input voltage	9 V
Power source type	DC

Weight and Dimensions

Depth	165 mm
Width	305 mm
Height	56 mm
Weight	800 g
