Behringer U-CONTROL UMX490 User Manual

11 U-CONTROL UMX490/UMX610 User Manual
behringer.com
The enormous value range of a total of 128 x 128 = 16,384 different values is
therefore available to you via the BANK SELECT command. This theoretically
means that you could use external devices which support the same amount of
different banks.
If you consider that each of these banks again contains another 128 individual
programs, you will receive the unbelievably large number of 2,097,152 different
options to organize these programs.
Press the ASSIGN push-button and hold it down.1)
Press one of the 16 channel keys 2)
CH 1
through
CH 16
,
or press the
GLOBAL
key.
Release the ASSIGN push-button.3)
Press the 4)
BANK MSB
key. Then press the number keys in sequence until
you have completely entered the desired BANK MSB number. Only value
entries between 0 and 127 are possible. Greater values are ignored by
the device.
The BANK MSB has now been defined.
Examples:
Press •
1
and
4
if you have decided on MSB 14,
for example.
Press •
1
,
0
and
7
if you would like to select
MSB 107.
Now define the 5)
BANK LSB
by pressing the key. Then enter the number
value of the BANK LSB with the already familiar procedure (see step 4).
The same entry rules apply as for the BANK MSB.
You have defined the bank in which the desired program will be called
up in steps 4 and 5. Now all you have to define is the program itself:
Press the 6)
PROGRAM
key and then press the number keys in sequence
until you have completely entered the desired program number.
Only entries between 0 and 127 are possible, greater values are ignored
by the device. Ready!
Finally, press the 7) ENTER key. In order to discard your assignments,
please press the CANCEL key or press the ASSIGN push-button again.
The ASSIGN LED will go off in all 3 cases.
Example:
You want to select preset No. 49 in bank 25 of an external device on channel
14 via the UMX. Only the LSB will be used to describe the bank, since the bank
number remains less than 128. The MSB in this case equals 0.
Press and hold the ASSIGN push-button.1)
Press the channel key 2)
CH 14
.
Release the ASSIGN push-button.3)
Then, press the 4)
BANK MSB
key or the
0
key
Press 5)
BANK LSB
key and then describe bank 25 with push-buttons
2
and
5
.
Define the program: Press the 6)
PROGRAM
key and then the
4
and
9
keys for program 49.
Press the 7) ENTER key.
Direct program selection through the two OCTAVE SHIFT c)
push-buttons.
Press the ASSIGN push-button and 1) hold it down.
Select the OCTAVE SHIFT push-button which you want to assign to the 2)
program change function.
Release the ASSIGN push-button again.3)
Defined the channel by which the program change will be transmitted. 4)
Press one of the 16 channel keys
CH 1
through
CH 16
on
the keyboard.
Press the 5)
PROG DIR
key. Then press the number keys on the
keyboard in sequence until you have completely entered the desired
preset number. Only value entries between 0 and 127 are possible.
Greater values are ignored by the device.
Finally, press the 6) ENTER key. In order to discard your assignments,
please select the CANCEL key or press the ASSIGN push-button again.
The ASSIGN LED will go off in all 3 cases.
As soon as you have assigned the direct program selection to one or ◊
both OCTAVE SHIFT push-buttons simultaneously, pressing both
push-buttons will not activate ANYTHING!
Other functions of the OCTAVE SHIFT buttons4.2.9
The OCTAVE SHIFT push-buttons of the device are in their initial state every time
the UMX is switched on (see Table 3.1). Further special functions can be assigned
to both push-buttons in the ASSIGN mode in addition to the already covered
functions regarding direct program change and octave transposition:
Transposition in individual semitone stepsa)
Sequential scrolling in program librariesb)
Optional controller functionsc)
As soon as you assign a function to one of the two push-buttons, ◊
the second push-button will automatically assume the same function,
however, it is still restricted in its functionality. It is not capable of
sending data until you assign a function to this push-button with the
ASSIGN procedure.
Transposition in individual semitone stepsa)
Press the ASSIGN push-button and 1) hold it down.
Press the 2)
TRANSP +/-
key.
Release the ASSIGN push-button.3)
Finally, press the 4) ENTER key. In order to discard your assignments,
please press the CANCEL key or press the ASSIGN push-button again.
The ASSIGN LED will go off in all 3 cases.
Pressing the right hand one of the two push-buttons causes a shift by one
semitone upward pressing the left hand one leads to a shift by one semitone
downward. Pressing both push-buttons cancels all transpositions.
A keyboard can consist of a maximum of 128 semitones according to ◊
the MIDI standard. If you have reached the lower or upper end of this
tone range with the transposition function, you cannot exceed the
highest or lowest tone despite continued pressing of the transposition
push-button. This also applies to the transposition in octave steps.

Behringer U-CONTROL UMX490 Specifications

General

MIDI-keyboard number of keys	49 keys
Product color	Red, White
Interface	USB
DC-in jack	Yes
USB version	2.0
USB ports quantity	1
Power source type	-
Power consumption (typical)	0.9 W

Weight and Dimensions

Depth	215 mm
Width	825 mm
Height	97 mm
Weight	3900 g
