U-PHORIA UMC404/UMC204/UMC202/UMC22/UM2
Quick Start Guide27
26
(15) OUTPUT (UM2 / UMC22 / UMC202) / MAIN
OUT (UMC204 & UMC404) knob adjusts the
output level at the 1(L) & 2(R) OUTPUTS
(UM2 / UMC22 / UMC202) or the L & R
MAIN OUT (UMC204 & UMC404).
(16) POWER LED indicates that the unit is
poweredon.
(17) +48 V LED indicates that +48 V phantom
power isengaged.
(18) output. Connect to headphones for
playback andmixing.
(19) USB type B connector. Connect to a
computer via thisconnector.
(20) +48 V ON/OFF selector engages
+48 V phantom power
(required for professional studio
condensermicrophones).
(21) 1(L) & 2(R) OUTPUTS (UM2 / UMC22 /
UMC202) / L & R MAIN OUT (UMC204
& UMC404) connect to powered studio
monitors for playback andmixing.
(22) DC IN (UMC404) connect to the mains via
the included power adapter.
(23) MIDI IN/OUT (UMC204 & UMC404)
connect to external MIDI controllers and
modules via theseconnectors.
(24) PLAYBACK OUTPUTS A 1 & 2 / B 3 & 4
(UMC204) / PLAYBACK OUTPUTS A 1/L
& 2/R / B 3/L & 4/R (UMC404) connect
to external speakers for additional
monitoring options.
(25) INSERTS 1 & 2 (UMC204) / 1 – 4 (UMC404)
connect to external signal processing
devices via theseconnectors.
(EN) Step 2: Controls
(1) MIC/LINE 1 (UM2 & UMC22) / INPUT
1 & 2 (UMC202 & UMC204) / INPUT
1 – 4 (UMC404) combination XLR/ ¼"
connectors. Connect microphones,
instruments or line level audio sources to
theseconnectors.
(2) INST 2 (UM2 & UMC22) ¼" connector.
Connect instrument and audio sources to
this connector.
(3) LINE / INST (UMC202 / UMC204 /
UMC404) selector designates line level
or instrument level input source at
combination XLR/¼"connector(s).
(4) PAD (UMC202 / UMC204 / UMC404)
selector reduces input level for connected
sources whenengaged.
(5) DIRECT MONITOR (UM2 / UMC22
/ UMC202) selector activates direct
monitoring of input signals with zero
latency (no delay) whenengaged.
(6) STEREO/MONO (UMC204 & UMC404)
selector activates mono monitoring
of audio signals connected to INPUT 1
and INPUT 2 (UMC204) or INPUTS 1 – 4
(UMC404) when engaged.
(7) MIX (UMC204 & UMC404) knob adjusts
the level of input signal to playback 1-2
signal at the MAIN OUT and at the
output (ifMONITOR A is selected for the
output).
(8) MONITOR A/B (UMC204 & UMC404)
selector designates output channels
3 & 4 at the output when engaged.
(9) PHONES (UMC202 / UMC204 / UMC404)
knob adjusts the output level at the
(headphones)output.
(10) SIG LED indicates that an audio signal is
present in the channel.
(11) MIC/LINE GAIN 1 (UM2) / GAIN 1 &2
(UMC22 / UMC202 /UMC204) GAIN 1 – 4
(UMC404) knob adjusts the input level
at MIC/LINE 1 (UM2), MIC/LINE 1 & INST
2 (UMC22), INPUT 1 & 2 (UMC202 &
UMC204), or INPUT 1 – 4 (UMC404).
(12) INST GAIN 2 (UM2) knob adjusts the input
level at the INST 2 input.
(13) CLIP LED indicates that the audio
signal in the channel is too loud.
Turn the corresponding GAIN knob
counter-clockwise until the CLIP LED
nolongerilluminates.
(14) MIDI IN/OUT LEDs (UMC204 & UMC404)
indicate MIDI signal activity.
U-PHORIA UMC404/UMC204/UMC202/UMC22/UM2 Controls
