ULTRAMATCH PRO SRC2496
6. SPECIFICATIONS
6. SPECIFICATIONS
Synchronization
Internal sampling rates 32, 44.1, 48, 88.2, 96 kHz
Synchronization via digital input
and wordclock accepts all sampling rates
between 31 and 100 kHz,
automatic synchronization by PLL
Digital input 1
Type XLR, transformer-balanced
Input impedance 110 ohms
Nominal input level 0.2 V to 5 V, peak-to-peak
Digital input 2
Type RCA, transformer-balanced
Input impedance 75 ohms
Nominal input level 0.2 V to 5 V, peak-to-peak
Digital input 3
Type Toslink, optical fiber cable
Synchronization input
Type BNC
Input impedance 50 kohms
Standard Wordclock (1 x FS)
Nominal input level 2 V to 6 V peak-to-peak
Digital output 1
Type XLR, transformer-balanced
Output impedance 110 ohms balanced
Nominal output level 3.5 V peak-to-peak
Digital output 2
Type RCA, transformer-balanced
Output impedance 75 ohms
Nominal output level 0.5 V, peak-to-peak
Digital output 3
Type Toslink, optical fibre cable
Analog inputs
Type XLR, balanced
Input impedance 20 kohms
Converter 24-bit/96 kHz
128/64 times oversampling
delta-sigma AKM A/D converter
Input level -4 dBu to +22 dBu for 0 dBFS,
adjustable
S/N-Ratio >105 dB
Analog outputs
Type XLR, balanced
Output impedance 160 ohms
Converter 24 bit/96 kHz
128 times oversampling
delta-sigma AKM D/A converter
Output level +16 dBu @ 0 dBFS
S/N Ratio >108 dB
Jitter suppression
Jitter permitted at input >40 ns
Internal jitter at input <2 ns
Internal jitter with external
Synchronization <20 ns, 10 ns typ.
Channel Status information in output signal
Professional mode Professional, audio use, stereo,
no emphasis or 50/15 µs,
Fs = 32, 44.1, 48, 88.2, 96 kHz
Consumer mode Consumer, audio use, 2-channel,
original material switchable,
copy permit switchable,
no emphasis or 50/15 µs,
Fs = 32, 44.1, 48 kHz;
(88.2, 96 kHz not defined)
Power supply
Mains voltage U.S.A./Canada 120 V ~, 60 Hz
U.K./Australia 240 V ~, 50 Hz
Europe 230 V ~, 50 Hz
General export model 100 - 120 V ~, 200 - 240 V ~,
50 - 60 Hz
Power consumption approx. 12 W
Fuse 100 - 120 V ~: T 200 mA H
200 - 240 V ~: T 100 mA H
Mains connection Standard IEC receptacle
Dimensions/weight
Dimensions approx. 1 3/4" (44.5 mm) x 19"
(482.6 mm) x 7 1/2" (190.5 mm)
Weight approx. 2 kg
Shipping weight approx. 3.2 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a
result of these efforts, modifications may be made from time to time to existing products
without prior notice. Specifications and appearance may differ from those listed or
illustrated.

Behringer Ultramatch Pro SRC2496 Specifications

General

Digital audio coaxial in	0
Digital audio optical in	1
S/PDIF out port	Yes
I/O ports	3x XLR In, 3x XLR Out, Toslink In, Toslink Out, BNC In, RCA In, RCA Out
Product color	Black, Stainless steel
Operating voltage	240 V
Power consumption (typical)	15 W

Weight and Dimensions

Depth	217 mm
Width	483 mm
Height	44.5 mm
Weight	2300 g
