24 PRO MIXER SERIES VMX1000USB/VMX300USB/VMX200USB/VMX100USB Quick Start Guide 25

Specications Especicaciones técnicas

VMX1000USB VMX300USB VMX200USB VMX100USB

Audio Inputs

Mic In Balanced XLR, 40 dB gain ¼" TRS, 46 dB gain ¼" TRS, 40 dB gain ¼" TRS, 53 dB gain

Phono In Unbalanced RCA, 40 dB gain

Line In Unbalanced RCA, 0 dB gain

Return Unbalanced RCA, 0 dB gain Unbalanced RCA, 0 dB gain Unbalanced RCA, 0 dB gain —

Mic Aux Return ¼" unbalanced, 3 dB gain — — —

Audio Outputs

Main Out (A) max. 25 dBu, balanced XLR max. +21 dBu @ +5 dBu (line in) max. +21 dBu @ +10 dBu (line in) max. +21 dBu @ +15 dBu (line in)

Main Out B max. 21 dBu, unbalanced — — —

Booth — max. +13 dBu — —

Tape Out typically 0 dBu

Send — — —

Mic Aux Send -∞ to +6 dBu — — —

Phones Out max. 180 mW @ 75 Ω typically 125 mW @ 1% THD typically 125 mW @ 1% THD typically 125 mW @ 1% THD

Subwoofer

Subwoofer Out Balanced XLR — — —

X-Over Variable 30 - 200 Hz — — —

Level -∞ to 0 dBu @ 0 dB input — — —

Equalizer

Stereo Low +12 dB/-32 dB @ 50 Hz

Stereo Mid +12 dB/-32 dB @ 1.2 kHz +12 dB/-32 dB @ 1.2 kHz +12 dB/-32 dB @ 1.2 kHz —

Stereo High +12 dB/-32 dB @ 10 kHz

Mic Low +15/-15 dB @ 80 Hz +12/-12 dB @ 50 Hz +12/-12 dB @ 50 Hz —

Mic Mid +15/-15 dB @ 2.5 kHz — — —

Mic High +15/-15 dB @ 12 kHz +15/-15 dB @ 12 kHz +15/-15 dB @ 12 kHz —

Kill Low — -54 dB @ 50 Hz — —

Kill Mid — -44 dB @ 1 kHz — —

Kill High — -26 dB @ 10 kHz — —

USB

Audio Stereo In/Out

Connector Type B

Converter 16-bit

Sample rate 48 kHz

System Specications

Signal-to-noise ratio >80 dB (line) >85 dB (line) >86 dB (line) >88 dB (line)

Crosstalk <-70 dB (line) >77 dB (line) >77 dB (line) >67 dB (line)

Distortion (THD) <0.05% <0.05% <0.06% <0.025%

Frequency response 20 Hz - 20 kHz

Input gain adjustment -20 dB - +9 dB

Power Supply

Mains voltage

USA/Canada 120 V~, 60 Hz

UK/EU/SAA/CCC 230 V~,50 Hz

Japan 100 V~, 50-60 Hz

Power consumption 22 W max. 22 W max. 13 W max. 10 W

Fuse

100-120 V~: T 500 mA H 250 V

220-230 V~: T 250 mA H 250 V

100-120 V~: T 500 mA L 250 V

220-230 V~: T 315 mA L 250 V

100-120 V~: T 400 mA L 250 V

220-230 V~: T 250 mA L 250 V

100-120 V~: T 160 mA L 250 V

220-230 V~: T 80 mA L 250 V

Mains connection Standard IEC receptacle

Dimensions/Weight

Dimensions (H x W x D)

4.2 x 8.8 x 19.0"

107 x 223 x 483 mm

3.5 x 9.5 x 13.7"

90 x 241 x 349 mm

3.5 x 8 x 11 .7"

90 x 203 x 298 mm

2.8 x 8 x 9.0"

72 x 203 x 229 mm

Weight 8.1 lbs / 3.7 kg 7.5 lbs / 3.4 kg 6.0 lbs / 2.7 kg 4.4 lbs / 2 kg

VMX1000USB VMX300USB VMX200USB VMX100USB

Entradas Audio

Entrada Micro XLR balanceado, 40 dB ganancia TRS 6,3 mm, 46 dB ganancia TRS 6,3 mm, 40 dB ganancia TRS 6,3 mm, 53 dB ganancia

Entrada Giradiscos RCA no balanceado, 40 dB ganancia

Entrada de Línea RCA no balanceado, 0 dB ganancia

Retorno RCA no balanceado, 0 dB ganancia RCA no balanceado, 0 dB ganancia RCA no balanceado, 0 dB ganancia —

Retorno Micro Aux

6,3 mm no balanceado,

3 dB ganancia

— — —

Salidas Audio

Salida principal A máx. 25 dBu, XLR balanceado máx. +21 dBu @ +5 dBu (line in) máx. +21 dBu @ +10 dBu (line in) máx. +21 dBu @ +15 dBu (line in)

Salida principal B máx. 21 dBu, no balanceado — — —

Cabina — máx. +13 dBu — —

Salida de pletina típico 0 dBu

Envío — — typically 0 dBu —

Envío micro auxiliar -∞ a +6 dBu — — —

Salida de auriculares máx. 180 mW @ 75 Ω típico 125 mW @ 1% THD típico 125 mW @ 1% THD típico 125 mW @ 1% THD

Subwoofer

Salida subwoofer XLR balanceado — — —

Separación de canales Variable 30 - 200 Hz — — —

Nivel -∞ a 0 dBu @ entrada 0 dB — — —

Ecualizador

Graves stereo +12 dB/-32 dB @ 50 Hz

Medios stereo +12 dB/-32 dB @ 1.2 kHz +12 dB/-32 dB @ 1.2 kHz +12 dB/-32 dB @ 1.2 kHz —

Agudos stereo +12 dB/-32 dB @ 10 kHz

Graves micro +15/-15 dB @ 80 Hz +12/-12 dB @ 50 Hz +12/-12 dB @ 50 Hz —

Medios micro +15/-15 dB @ 2.5 kHz — — —

Agudos micro +15/-15 dB @ 12 kHz +15/-15 dB @ 12 kHz +15/-15 dB @ 12 kHz —

Graves Kill — -54 dB @ 50 Hz — —

Medios Kill — -44 dB @ 1 kHz — —

Agudos Kill — -26 dB @ 10 kHz — —

USB

Audio Entrada/salida stereo

Conector Tipo B

Convertidor 16 bits

Frecuencia de muestreo 48 kHz

Especicaciones Del Sistema

Relación señal-ruido >80 dB (línea) >85 dB (línea) >86 dB (línea) >88 dB (línea)

Crosstalk o cruce de canal <-70 dB (línea) >77 dB (línea) >77 dB (línea) >67 dB (línea)

Distorsión (THD) <0.05% <0.05% <0.06% <0.025%

Respuesta de frecuencia 20 Hz - 20 kHz

Ajuste de ganancia de entrada -20 dB - +9 dB

Alimentacion

Voltaje

EE.UU./Canadá 120 V~, 60 Hz

Reino Unido/Europa/SAA/CCC 230 V~,50 Hz

Japón 100 V~, 50-60 Hz

Consumo 22 W máx. 22 W máx. 13 W máx. 10 W

Fusible
