Technical data
Beijer Electronics AB, MA00557F A-5
Technical data for CIMREX 12
Parameter CIMREX 12
Front panel, W x H x D 142 x 90 x 3 mm
Mounting depth 43.3 mm excl. D-sub and 108.5 mm incl. D-sub
Front panel seal IP 65, NEMA 4X (indoor use only)
Rear panel seal IP 20
Keyboard material
Membrane switch keyboard with polyester domes.
Overlay film of Autotex F207 * with print on reverse side.
1 million operations.
Reverse side material Alu-Zinc
Weight, excl. D-sub 0.37 kg
Serial port RS422
25-pin D-sub contact, chassis-mounted female with standard
locking screws 4-40 UNC.
Serial port RS232C
9-pin D-sub contact, chassis-mounted male with standard lock-
ing screws 4-40 UNC.
Serial port RS485 Available through RS422. Requires software configuration.
Flash memory for appli-
cation
64 kb
Real time clock
±10 PPM + error because of ambient temperature and supply
voltage. Total max error: 1 min/month = 12 min/year.
Minimum life of the real time clock battery: 10 years.
Power consumption at
rated voltage
Max: 150 mA.
Display
STN-LCD. 2 lines of 20 characters, 5.55 mm character height.
LED backlight lifetime at the ambient temperature of +25 °C:
50,000 h. Backlight dimming 0-100%.
Active area of display,
W x H
75.4 x 11.5 mm
Contrast setting
Adjust potentiometer on the back of the terminal using an
appropriate tool, such as a plastic screw driver, in order to limit
the risk of short-circuiting or other injury.
Power supply
+24 V DC (20-30 V DC) 3-pin jack connection block.
CE: The power supply must conform with the requirements for
SELV or PELV according to IEC 950 or IEC 742.
Fuse 800 mAT, 5 x 20 mm
Ambient temperature 0 ° to +50 °C
Storage temperature -20 ° to +70 °C
Relative humidity Max. 85 % non-condensed
EMC tests on the
terminal
The terminal conforms with the essential protection require-
ments in article 4 of the directive 89/336/EEC. Noise tested
according to EN61000-6-3 emission and EN61000-6-2 immunity.
