Technical data
Beijer Electronics AB, MA00557F A-1
Technical data
Technical data for CIMREX 5
Parameter CIMREX 5
Front panel, W x H x D 104 x 69 x 3.5 mm
Mounting depth 35 mm with or without D-sub
Front panel seal IP 65, NEMA 4X (indoor use only)
Rear panel seal IP 20
Keyboard material
Membrane switch keyboard with polyester domes. Overlay film
of Autotex F207 * with print on reverse side. 1 million opera-
tions.
Reverse side material Alu-Zinc
Weight, excl. D-sub 0.2 kg
Serial port RS422
25-pin D-sub contact, chassis-mounted female with
standard locking screws 4-40 UNC.
Serial port RS232C
A RS232C port is available when the enclosed adapter 232-25-
ADP is mounted on the RS422 port.
Flash memory for appli-
cation
16 kb
Power consumption at
rated voltage
Max: 200 mA
Display
STN-LCD. 2 lines of 16 characters, 5 mm character height.
LED backlight lifetime at the ambient temperature of +25 °C:
50,000 h.
Active area of display,
W x H
55.7 x 11.0 mm
Contrast setting
Adjust potentiometer on the back of the terminal using an
appropriate tool, such as a plastic screw driver, in order to limit
the risk of short-circuiting or other injury.
Power supply
+5 V DC ±5 % from controller system or externally.
Battery eliminator (connector 2.1 mm, center pin 0 V).
Ambient temperature 0 ° to + 50 °C
Storage temperature -20 ° to +70 °C
Relative humidity Max. 85 % non-condensed
EMC tests on the
terminal
The terminal conforms with the essential protection require-
ments in article 4 of the directive 89/336/EEC. Noise tested
according to EN50081-1 emission and EN61000-6-2 immunity.
UL approvals UL 508, UL 1604 (Class I, Div 2, Groups A, B, C, D, T4)
