Supported Interfaces QTERM-G55 Terminal
38
Qlarity-Based Terminal Hardware
3.2.1.6.1 Power Interface with Integral Cable
The following table shows the pinout for each type of power interface when the integral cable
option is selected.
3.2.1.6.2 Primary Serial Interface with Integral Cable
The following table shows the pinout for each type of serial interface.
3.2.1.6.3 Secondary Serial Interface or Network Interface with Integral Cable
The following table shows the pinout for each type of secondary serial interface or network
interface.
3.2.1.7 E-stop Option with Integral Cable
If the terminal is equipped with the E-stop option and integral cable, the DB15f pinout changes
to accommodate the switch signals, as shown below. Note that a secondary serial interface is
not available if the E-stop option is selected.
DB15f Pin
Regulated
(standard)
5 Volt Unregulated Power-over-Ethernet
9 8 - 32 VDC 4.5 - 5.5 VDC No connect
1 Ground Ground Ground
15 No connect No connect PoE V+
8 No connect No connect PoE V-
DB15f Pin EIA-232 EIA-422 EIA-485
11 Tx Tx+ RTx+
5 RTS (out) Tx- RTx-
12 Rx Rx+ No connect
4 CTS (in) Rx- No connect
DB15f Pin EIA-232 EIA-422 EIA-485
Ethernet
(including PoE)
7TxTx+RTx+Tx+
14 RTS (out) Tx- RTx- Tx-
6 Rx Rx+ No connect Rx+
13 CTS (in) Rx- No connect Rx-
