Operator Panel Drawings

5 Opera torPanelDrawings

5.1 Connectors

1234

COM 3/4LANCOM 1/2

Pos. Connector Description

1 Powersupply +24VDC(18-32VDC)

2 COM1/2 CommunicationPorts

3 LAN 1×10 /100Base-T(shieldedRJ45)

4 COM3/4 CommunicationPorts

5.2 CommunicationPorts

Serialport,9-pinfemale Serialport,9-pinfemale

COM1 COM2 COM3

RS422Tx+

RS485Tx+/Rx+

- RS485Tx+/Rx+

2 RS232RxD - RS232RxD -

3 RS232TxD - RS232TxD -

4- RS422Rx+ - -

5 GND GND GND GND

RS422Tx-

RS485Tx-/Rx-

- RS485Tx-/Rx-

7RS232RTS - - -

8 RS232CTS - - -

9- RS422Rx- - -

BeijerElectronics, MAEN181B
