14
The back
wall of the wooden cabinet must be left open completely to kitchen wall in order to allow
sufficient air circulation to cool down the condenser unit for energy efficiency.
1775 mm
855 mm
32 mm
1778-1788 mm
No wooden
back wall
71
mm
540 mm
545 mm
40
mm
775 mm
1775 mm
855 mm
INSTALLATION INSTRUCTIONS
DETAILED STEP BY STEP
555 mm
mm
Adjusting the legs
If your refrigerator is unbalanced:
You can balance your refrigerator by turning the legs of it as illustrated in the figure. The corner where
the leg exists is lowered when you turn in the direction of black arrow and raised when you turn in the
opposite direction. Taking help from someone to slightly lift the refrigerator will facilitate this process.
