Beko BCFD373 - Reversing the Doors; Reversing the Top Door; Reversing the Lower Door

21
REVERSING THE DOORS
Proceed in numerical order.
1
4
3
6
2
5
7
8
9
10
16
18
19
20
14
15
17
12
13
11
Top door
1. Unscrew top hinge (1).
2. Carefully remove the top door
(2).
3. Unscrew lower hinge (3).
4. Remove plastic plugs (7 & 8).
5. Refit top hinge (1) as lower
hinge (16) on the left hand
side.
6. Replace top door (17).
7. Refit lower hinge (3) as top
hinge (18) on the left hand
side.
Lower door
1. Unscrew top hinge (4).
2. Carefully remove the lower
door (5).
3. Unscrew lower hinge (6).
4. Remove plastic plugs (9 &10).
5. Refit hinge (4) as lower hinge
(11) on the left hand side.
6. Replace lower door (12).
7. Refit lower hinge (6) as top
hinge (13) on the left hand
side.
Refit plastic plugs (7, 8, 9 & 10)
into the screw holes on the right
hand side (14, 15, 19 & 20).
