belavi 21224-21 - Hardware List; Assembly Instructions

6 AFTER SALES SUPPORT
support@tdcusainc.com 1800 599 8898
MODEL: 21224-21 PRODUCT CODE: 1958 05/2021
AFTER SALES SUPPORT 7
1800 599 8898 support@tdcusainc.com
MODEL: 21224-21 PRODUCT CODE: 1958 05/2021
Assembly Instructions
B
G
D
C
F
STEP 1:
Place the Top Cross Bar (C) over the Bottom Cross Bar (D) to form an “X.”
Attach the Bottom Pole (B) to the cross bars using the four Bolts (F) with
provided washers.
Hardware List
A
F
E
C
B
A
D
G
