Specifications
General
Frequency range UHF:400-480 MHz
Channel Capacity 1024
Zones 64
Channel Spacing 12.5KHz
Operating Voltage DC 13.8V (±20%)
Frequency Stability ±1.5ppm
Antenna Impedance 50Ω
Dimensions (L×W×H) 162（L）* 157(W)* 51 (H)mm
Weight 1300g
Transmitter
RF Output Power High Power： 50W
Middle Power：25W
Low Power：10W
4FSK Modulation 12.5kHz Only data：7K60FXD
12.5kHz data and audio：7K60FXE
FM Noise -40dB
Conducted Emission -36 dBm≤1GHz/-30 dBm≥1GHz
Adjacent Channel Power ≤-60dB
Audio Response +1/-3 dB
Audio Distortion 3%
Digital Voice coder Type AMBE3000
Receiver
Digital Sensitivity 5% BER：0.25 uV
Intermodulation 60dB
Adjacent Channel Selectivity 60 dB
Spurious Response Rejection 60 dB
Audio output power 5W
Audio Distortion 3% (Typical)
Working Temperature -20℃—+70℃
Storage Temperature -30℃—+85℃
