Belimo 22G14-5C - Page 12

Digital gas monitoring
3.2.3 Wiring Model 22Gxx-5C & C-22G-5C
Network end of
line jumper
Transformer
24 V AC/DC
3 VA/W for
each unit
Independent circuit
120 VAC
To other
units
CAN bus
network
High (H)
Low (L)
Shield
(on 1st
unit only)
