Digital gas monitoring
7.0 BACnet Network Conguration
For instructions on changing settings see section 4.3
Setting 46 Bacnet Mode select
0 = communication disabled
1 = communication enabled
2 = communication enabled and
display all monitors on
CAN network
0, 1, 2 Default 0
Setting 47 BMA MAC address 0-127 0
Setting 48 Baud rate 0 = 9600
1 = 19200
2 = 38400
3 = 76800
3
Setting 53 Max Master 0-127 127
Setting 54 Diagnostic tool to test MSTP
communication. Format
XXXXYYZZ where YY= ID of
device that passed token to
current sensor and ZZ = ID of
device that received token.
Setting 70 Device ID 4,194,303 60,000+BMA
Ventilation Controlled by BACnet Building Automation
120 Vac 24 V AC/DC
Transformer for sensors
only. Do not use 24 V AC/
DC from BMS
